How Does Slope Affect Water Runoff? A Simple Home Experiment

Overview

When rain falls on the ground the water can either soak into the soil, evaporate, or travel over the surface to a stream. The portion that moves across the land is called surface runoff and it is the main source of flow during a flood [1]. One of the most important landscape features that controls how much water becomes runoff is the slope of the land. This experiment lets children see directly how steeper slopes produce more runoff.

Testable Question

How does the steepness of a surface affect the volume of water that runs off after a simulated rainstorm?

Hypothesis

If the slope of the surface is increased, then the amount of runoff collected will increase because water moves faster downslope and has less time to infiltrate [3].

Materials

• Four pieces of sturdy cardboard (about 30 cm × 30 cm each)
• White printer paper or thin craft paper (to line the cardboard)
• Measuring cup (100 mL capacity)
• Clear plastic container or large bowl (to collect runoff)
• Ruler or carpenter’s level
• Protractor or a simple angle guide (e.g., a stack of books) to set slopes
• Water at room temperature
• Timer or stopwatch
• Marker and notebook for recording data

Before You Begin

Find a flat work surface where the cardboard trays can be tilted safely. An adult should help set the angles and supervise the use of water to avoid spills.

Procedure (Steps)

1. Cut the cardboard into four identical squares if not already sized.
2. Cover each square with a sheet of paper to make the surface smooth and to help observe water flow.
3. Label the cardboard pieces “0°”, “5°”, “10°”, and “15°” (or use percent slope equivalents, e.g., 0 %, 9 %, 18 %, 27 %).
4. Place the first cardboard piece on the work surface so it is perfectly level (0°). Use the ruler and level to confirm.
5. Position the plastic container directly beneath the lowest edge to catch any water that runs off.
6. Measure 100 mL of water in the measuring cup. Quickly pour the water onto the center of the cardboard, simulating a short rainstorm.
7. Start the timer as you pour. Observe how long it takes for the water to stop flowing off the edge and record the total runoff volume that collects in the container.
8. Empty and dry the container, then repeat steps 4‑7 for the same cardboard set at 5°, 10°, and 15° slopes. To set a slope, place a stack of books or a wedge under one side of the board until the desired angle is reached; verify with the protractor.
9. Perform at least three trials for each slope to see natural variation.
10. After the final trial, clean up any spilled water and store the cardboard for future use.

Variables and Controls

• Independent variable: Slope angle of the cardboard (0°, 5°, 10°, 15°).
• Dependent variable: Volume of runoff collected (milliliters).
• Controlled variables: Amount of water poured (100 mL each trial), size of the cardboard, type of paper lining, ambient temperature, and the time allowed for runoff to finish (stop when water no longer leaves the board).

Repeated Trials

Repeating each slope three times helps identify random errors such as slight differences in pouring speed or tiny gaps in the paper lining. Record each trial separately and later calculate an average runoff for each slope.

What to Observe or Measure

• Time from start of pour to the moment runoff stops (seconds).
• Volume of water collected in the container (mL). Use the measuring cup to transfer the water from the container to the cup for accurate measurement.
• Visual notes: does the water spread out more on gentle slopes? Does it form a thin sheet on steep slopes?

Data Table

Graphing Your Results

Create a simple bar graph or scatter plot with slope angle on the horizontal axis and average runoff volume on the vertical axis. If you have a spreadsheet program, plot the points and add a trend line. The trend line often follows a logarithmic shape, as research on variable‑slope boxes found runoff volume increased with the natural logarithm of slope (%slope + 0.1) [4].

The Science Explained

When rain lands on a surface, gravity pulls the water downhill. On a gentle slope, water spreads out, slows down, and has more opportunity to soak into the soil (infiltration). On a steep slope, water accelerates, forms a thin, fast‑moving sheet, and spends less time in contact with the ground, so less water infiltrates and more becomes runoff [1]. Runoff is a key part of the water cycle because it carries water, sediments, and nutrients to streams and lakes [2]. The amount of runoff from a watershed depends on many characteristics, including slope, soil type, land cover, and drainage area [3]. By isolating slope in this experiment, we see one of the strongest controls on runoff volume.

Troubleshooting

• Very little runoff on a steep slope: The paper lining may be too absorbent, allowing water to soak into it. Use a smoother, less absorbent surface (e.g., a thin sheet of plastic).
• Runoff spills outside the container: Reduce the distance between the board edge and the container or use a larger container.
• Inconsistent volumes between trials: Make sure the water is poured at the same rate each time. Practice a steady pour before recording data.

Try Another Version

Change the ground cover: place a layer of sand, soil, or grass clippings on the cardboard before each trial. This extension explores how surface imperviousness (the ability of a surface to let water pass through) interacts with slope to affect runoff.

Cleanup and Disposal

All water can be poured down a drain. Dry the cardboard and paper, then store them for future use. No hazardous materials are involved.

Next Steps

Use the data to discuss real‑world examples, such as why steep hillsides are prone to flash floods or why engineers design terraces on slopes to reduce runoff.
